Features
Low insertion loss
High ER& Return loss
High Stability and reliability
Applications
Fiber Laser
Fiber Amplifiber
Testing Instrument
Optic lab use
Performance specifications
|
Parameters
|
Unit
|
Values
|
||||
|
Type
|
FC/APC; FC/UPC; LC/APC; LC/UPC; SC/APC; SC/UPC
|
|||||
|
Wavelength
|
nm
|
1310&1550
|
1064&980
|
850
|
780
|
|
|
Min. Insertion Loss
|
dB
|
0.3
|
0.4
|
0.7
|
0.9
|
|
|
Min.Return loss
|
APC
|
dB
|
60
|
|||
|
UPC
|
dB
|
50
|
||||
|
Min. Extinction Ratio 23℃
|
dB
|
23 | 23 | 22 | 21 | |
|
Fiber Type
|
PM13&PM15
|
PM98
|
PM85
|
Nufern
PM780 HP
|
||
|
Key Orientation
|
Slow Axis
|
|||||
|
Max. Axis Alignment
|
±3
|
|||||
|
Operating temperature
|
℃
|
0 ~ +70
|
||||
|
Storage temperature
|
℃
|
-40 ~ +85
|
||||
|
Note: For device with connector, IL is 0.3dB higher, RL is 5dB lower, ER is 2dB lower.
|
||||||
Ordering Information
PMJP-A-BCDE-F
| A | B | C | D | E | F |
|
Operating Wavelength
|
Fiber Type
|
Fiber Length
|
Tube Type
|
Connector Type
|
Connector
Type
|
|
1550: 1550nm
|
1: PM15
|
0: 0.8
|
1: 250μm fiber
|
0: None
|
0: None
|
|
1310: 1310nm
|
2: PM13
|
1：1m
|
2: 900μm loose tube
|
1: FC/UFC
|
1: FC/UFC
|
|
1064: 1064nm
|
3: PM98
|
2 : 2m
|
3: 2mm loose tube
|
2: FC/APC
|
2: FC/APC
|
|
980: 980nm
|
4:PM85
|
4: 3mm loose tube
|
3: SC/UPC
|
3: SC/UPC
|
|
|
……
|
4: SC/APC
|
4: SC/APC
|
|||
|
5: LC/UPC
|
5: LC/UPC
|
||||
|
6: LC/APC
|
6: LC/APC
|
