1x8 SC UPC Insertion Module Fiber Optical PLC Splitter.

1x8 SC UPC Insertion Module Fiber Optical PLC Splitter

1×8 SM Mini Tube PLC Splitter SC APC provided by OPTICO is an integrated waveguide optical power distribution device based on quartz substrate.Like coaxial cable transmission, optical network systems also need to couple, branch, and distribute optical signals, which requires optical splitters to achieve. Multiple input terminals and multiple output terminals at the same time.The micro PLC optical splitter with the micro box structure has stronger fiber protection performance than the bare fiber PLC optical splitter.

The internal structure of the PLC Splitter

Features:

• High Stability and Reliability
• Telcordia GR-1209 and GR-1221 Compliance
• YD/T 2000.1-2009 Compliance (TLC Product Certificate Compliance)
• Low Insertion Loss

Specification:
1x2, 1x4, 1x8, 1x16, 1x32, 1x64 splits
2x2, 2x4, 2x8, 2x16, 2x32, 2x64 splits
Fiber jacketing outside boxes 2mm and up to 3mm
ABS box type or inside metal box/module cassette type
SC/UPC, SC/APC, LC/UPC, LC/APC, FC/UPC, FC/APC, ST/UPC connector options
Custom connector configurations and combinations

Construction
Configuration Type: 1x2
Fiber Type: G.657A1
Glass: Corning® Clearcurve XB Bend Insensitive Fiber (BIF)
Fiber Diameter: 900 μm
Fiber Length: 1 m input/1 m output
Connector Type: None

Performance
Operating Wavelength: 1260-1650 nm
Insertion Loss: ≤16.9 dB
Polarization Dependent Loss (PDL): ≤0.3 dB
Return Loss: ≥55 dB
Uniformity: ≤1.5 dB
Directivity: ≥55 dB
Operating Temperature Range: -20 to 70°C (-4 to 158°F)
Storage Temperature Range: -20 to 70°C (-4 to 158°F)

Mission will be achieved in 7-15 days

FAQ:

1.Can I get a sample free?
Yes,you need place sample order to us, and we will reduce from next order .
2.How do I know your products are original and brand new ?
We guarantee products from our company are original and brand new.
We are the key distributor of Huawei,ZTE,Fiberhome, who get special offer and technical support from them. Each model has S/N number and we will send you the S/N list to you after shipping .You can confirm with manufactures.
You will get competitive price and professional technical supports.
3.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if you provide us the content and tell us where to put.
4.How can we place order?
Comfirm PI — Got the deposit — Arrange production/delivery
After we made agreement on the product's parameters, we will make proforma invoice for your confirmation. When we got your advance payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship forwarder to delivery goods. if not, then when the goods arrived at Destination port, you must find a ship forwarder help you clear the custom.
5.How about the shipping?
For small orders, we will send the goods by International Express like HK Fedex, DHL, TNT or UPS. Usually it takes about 7 workdays to arrive.If big quantity we will ship by Ocean transportation, it takes one month to arrive. if urgnet, you can select shipping by Air, but freight charge will be more expensive.
6.What's your products' advantages ?
A. Good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing, assemble, packing and shipping.
D. Good after-sale service. Professional online technical support can be provided. Moreover, if any problem of the goods, we will help to solve the problem or provide replacement of the goods.
