● General Description:
This 10Gigabit XFP BiDi transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 20km. The 10G XFP BiDi 20km optical module electrical interface is compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled. The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI. SFI typically operates over 200 mm of improved FR4 material or up to about 150mm of standard FR4 with one connector.
● Quick Specs:
► 100% Foundry Compatible;
► 10GBASE-ER XFP 1550nm 80km transceiver;
► High Quality with CE,RoHs,FCC.
● Quick Details:
► Hot-Pluggable XFP Optical Transceiver with LC connector;
► 10G Small Form-Factor Pluggable (XFP) MSA compatible;
► Compliant with XFP Multi-Sourcing Agreement (MSA);
► INF-8077i Digital Diagnostic Function (DMI);
► Maximum Link Length of 80KM;
► Support both +3.3V and +5V Power Supply;
► Low Power Dissipation < 3 Watts;
► RoHS Compliant;
► Class 1 Laser International Safety Standard IEC 60825 Compliant.
● Application:
► SONET(OC-192)/SDH(STM64) line card;
► 10GBASE-ER (10.3125Gbps);
► 10GBASE-EW (9.953Gbps);
► 10GE Ethernet switches and routers;
► 10GE Storage.
● Description:
| Form Factor | XFP |
Device Type | Transceiver module |
Interface (Bus) Type | Plug-in module |
Connectivity Technology | Wired |
Application | 10GBASE-ZR |
Data Transfer Rate | 10Gbps |
Wavelength | 1330nm-TX |
DDM | With DOM |
Storage | -40℃ to 85℃ |
Compliance | IEC-60825, FDA 21 |
Warranty | Lifetime |
Distance | 20km |
● Optical characteristics transceiver:
Parameter | Symbol | Min | Typ | Max | Unit | |
Maximum Launch Power | PMAX | -3 |
| +0.5 | dBm | |
Optical Center Wavelength | UBXFP-20-U | λ | 1260 | 1270 | 1280 | nm |
UBXFP-20-D | 1320 | 1330 | 1340 | |||
Optical Extinction Ratio | ER | 3.5 |
|
| dB | |
Spectral Width | Δλ |
|
| 1 | nm | |
Sidemode Supression ratio | SSRmin | 30 |
|
| dB | |
Rise/Fall Time (20%~80%) | Tr/Tf |
|
| 50 | ps | |
Optical Eye Mask |
| IEEE802.3ae | ||||
Operating Date Rate | BR | 9.95 |
| 11.3 | Gb/s | |
Receiver Sensitivity | Sen |
|
| -14.5 | dBm | |
Maximum Input Power | PMAX | 0 |
|
| dBm | |
Optical Center Wavelength | UBXFP-20-U | λC | 1320 | 1330 | 1340 | nm |
UBXFP-20-D | 1260 | 1270 | 1280 | |||
Receiver Reflectance | Rrx |
|
| -14 | dB | |
LOS De-Assert | LOSD |
|
| -15 | dBm | |
LOS Assert | LOSA | -30 |
|
| dBm | |
LOS Hysteresis | LOSH | 0.5 |
| 5 | dB | |
● Quality Certification:
Quality and standards are the foundation of FOCC. We are dedicated to providing customers with outstanding, standards-compliant products and services. FOCC has passed many quality system Certifications, like CE, RoHS, FCC, established an internationally standardized quality assurance system and strictly implemented standardized management and control in the course of design, development, production, installation and service. Please Note: Installing a third party transceiver does not void your network equipment warranty. Network equipment manufacturers all have guidelines stating that warranty support on their products will not be affected.
● Lifetime Warranty:
All the fiber optic products in FOCC are fully warranted against defects in material and workmanship with a lifetime guarantee. This warranty does not cover damage caused by accident, improper care, improper use, negligence, normal wear and tear, or the natural breakdown of colors and materials over extended time and use.
Bi-directional 10Gbps XFP transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification. They comply with 10-Gigabit Ethernet 10GBASE-LR/LW per IEEE 802.3ae, SONET OC-192 /SDH and 10G Fibre Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.
