3.5/4.0mm G657B3 SC APC outdoor patch cord cable fiber optic patch leads
FTTH 3.5mm SC APC singlemode simplex G657B3 fiber optic patch crods
FOCC can product Fiber Outdoor Exterior Pigtails ,inside 1.9mm inner white LSZH sheath, outer jacket is PE Material,it can be used indoor and outdoor . And outer black 3.5mm jacket can be stripped more easily if customer need use inside 1.9mm cable to connector with patch panels,terminal box and make splicing installation .The fiber we used G657A2 fiber.For this type pigtail length always 20M,30M,40M,60M,80M,100M,120M,2KM.
Features:
A. Available in G652D, G657A, OM1, OM2, OM3 and OM4 fiber types.
B. LSZH inner sheath and PE Outer shealth gives more excellent tensile strength,mechanial,rodent,ultraviolet and environmental protection.
Specification:
| Fiber Mode | Singlemode or Multimode |
Fiber Count | 1 |
Connector Stype | SC,FC,ST,LC,MU,DIN |
Polish or Ferrule Interface Type | PC,APC,UPC |
Cable Lengths | Custom Lengths |
Jacket Materials | PE Material |
Outer Jacket Color | Black |
Inner Jacket Color | White |
Outer Jacket Diameter(mm) | 3.5±0.1 |
Inner Jacket Diameter(mm) | 1.9±0.1 |
Storage Temperature | -20°C to 60°C |
Installation Temperature | -5°C to 50°C |
Operating Temperature | -20°C to 60°C |
Crush(N/100mm) | 1000 |
Maximum Tensile Load (Long term) | 150N |
Minimum Tensile Load (Short term) | 400N |
