1x4 PLC Fiber Splitter Blockless Splitter Mini Module, 900μm, SC/UPC LC/UPC SC/APC LC/APC Connector

● Technical Information: Planar Lightwave Circuit is a more recent technology. PLC splitters offer a better solution for applications where larger...

InquiryChat Now

  • Product Details

● Technical Information:
Planar Lightwave Circuit is a more recent technology. PLC splitters offer a better solution for applications where larger split configurations are required. To achieve this, waveguides are fabricated using lithography onto a silica glass substrate, which allows for routing specific percentages of light. As a result, PLC splitters offer very accurate and even splits with minimal loss in an efficient package. With the rapid growth of FTTX worldwide, the requirement for larger split configurations (1x32, 1x64, etc) in these networks has also grown in order to serve mass subscribers. Due to the performance benefits and overall low cost to deploy, PLC splitters are now the ideal solutions for these types of applications.


● Features:
► Wavelength Intensive;image001(001).jpg► Low Polarize on Dependence;
► Excellent Mechanical;
► Stability Telecordia GR-1221 and GR-1209;
► Components through TLC-Certified,Conform to YD1117-2001;
► Excellent Uniformity;
► High Polarization Extinction Ratio & Excellent Uniformity;
► Fiber input: 0.9mm or 250μm fiber for choice;
► Fiber output: 250μm bare fiber (It is benefit for splicing);
► Corning SMF-28e G.657A Fiber.


● Application:
► Fiber to the point (FTTX);
► Fiber to the home (FTTH);
► Passive optical networks(PON, GEPON);
► Local area networks (LAN);
► Cable television (CATV);
► Telecommunication Networks;
► Testing Equipment;
► Plug-in type optical Splitter compact structure, small size, easy to use, can be built in a variety of outdoor equipment, such as: 19-inch rack, the cross-connect cabinet floor junction boxes and other equipment;
► The fiber optic PLC Splitter tray compact, small, easy to use, can be built in a variety of devices, such as cable television networks, fiber optic LAN cable transfer boxes, cross-connect cabinets and fiber patch panels and other equipment;
► LGX Splitter widely used on 4U rackmount chassis in FTTH network;
► ABS Cassette PLC Splitter compact, small, easy to use, can be built in a variety of devices, such as: 19-inch rack, the cross-connect cabinets and other equipment.


● Specification:

Parameter

Port Configuration

1x2

1x4

1x8

1x16

1x32

1x64

Fiber Type

SMF-28e G.657A

Operating Wavelength (nm)

1260~1650

Insertion Loss(dB)

Typical

3.9

7.0

10.2

13.2

16.2

19.7

Max

4.2

7.4

10.7

13.7

17.1

21.2

Loss Uniformity (dB)

Max

0.4

0.6

0.8

1.2

1.5

2.5

Return Loss (dB)

Min

50

50

50

50

50

50

PDL(dB)

Max

0.2

0.2

0.3

0.3

0.3

0.4

Directivity(dB)

Min

55

55

55

55

55

55

Wavelength Dependent Loss(dB)

Max

0.3

0.3

0.3

0.5

0.5

0.8

Temperature Dependent Loss

Max

0.5

0.5

0.5

0.8

0.8

1.0

Operating Temperature ()

-40~+85

Storage Temperature ()

-40~+85

Note:
1. Above is the parameters for Blockless Fiber PLC Splitter with connectors.
2. Without connectors, the insertion loss will be 0.2dB lower.


● Mechanical Dimensions:



● Order Information:
(1) Configure include, but are not limited to: 1x2, 1x4, 1x8, 1x16, 1x32, 1x64, 2x2, 2x4, 2x8, 2x16, 2x32, 2x64;
(2) Optional connectors: LC, SC, FC, ST;
(3) The optional end face : UPC, APC;
(4) Default fiber length <= 1.5 m can be customized fiber modes are available: single mode, multi-mode;
(5) Optional Fiber Type: G652D, G657A1;
(6) Package Type: steel tube bare fiber, steel tube non-blocking, ABS boxes, LGX, a small plug-piece, tray, chassis.


● International Authoritative Certification
Compliance with the international ISO9001, CE, FCC, RoHS standards. FOCC strict implementation of standardized management and control of the design, development, production, installation and service.



● Advantage Details:
(1) High Environmental Stability
► Low insertion loss, low polarization dependent loss, low back reflection, and good uniformity;
(2) Excellent Quality Chips
► Loss of light is not sensitive for wavelength, and it can meet the transmission needs of different wavelengths;
(3) Compact Structure
► Small size, it can be directly installed in a variety of transfer box and just take up little space;
(4) Exquisite Packaging
► The design and packaging is exquisite to ensure the product in good condition.



● Workshop Overviews:
Among the total workshop area of more than 12,000 square meters, dust-free workshop room accupies 500 square meters while dust-proof room occupies 6,500 square meters.



● PLC More Family Products:

image009(001).jpg        image010(001).jpg

image011(001).jpg        image012(001).jpg


Welcome to buy the 1x4 plc fiber splitter blockless splitter mini module, 900µm, sc/upc lc/upc sc/apc lc/apc connector with our factory. As one of the leading manufacturers and suppliers in China, we also welcome the customized orders. Consult the price and the quotation with us now.
