FC UPC Big D Type 13mm Flange Simplex Singlemode/Multimode Metal Adapter

● Brief Introduction: Fiber Adaptor is used to provide a cable to cable or cable to equipment fiber optic connection. We provide a wide range of mating...

Inquiry

  • Product Details

● Brief Introduction:
Fiber Adaptor is used to provide a cable to cable or cable to equipment fiber optic connection. We provide a wide range of mating sleeves and hybrid adapters, including special male to female hybrid fiber optic adaptor.image001(001).jpg


● Feature:
► Low insertion loss and back reflection loss;
► Ferrule end surface pre-domed;
► RoHS compliant;
► Precision anti-rotation key and corrosion resistant body;
► Telcordia style boots;
► Free-floating ceramic ferrule;
► Zirconia sleeves or Phosphor bronze sleeves.


● Applications:



► High speed transmission systems;

► Fiber optic sensing;
► Industtial, Mechanical and Military;
► Fiber Optic Telecommunications;
► LAN (Local Area Network);
► FTTH (Fiber To The Home);
► CATV&CCTV System.


● Technical Specifications:


Parameters

FC/PC

FC/UPC

FC/APC

Working Temperature(℃)

-40  ~  +80

Insertion Loss (dB)

≤0.25

≤0.25

≤0.25

Return Loss( dB)

≥45

≥50

≥60

Repeatability

≤0.2dB

Durability

More than 1000 Times

Exchangeability

≤0.2dB

Sleeve material

Zirconia Ceramic, PB Sleeve

Housing Material

High quality plastic / zinic alloy with nickel plated / 59-1 copper with nickel plated



● Application Designed:
A fiber optic adapter or coupler is a special passive component designed to mate or connect two ends of a fiber optic cable with high precision. Fiber optic adapters mate two ends of different fibers optic connectors, achieving the conversion between different connectors FC, SC, ST,LC, MTRJ, MPO, E2000 and so on. They are widely used for Optical Distribution Frame (ODF),fiber optic communication device and equipment, with excellent performance, good stability.


● Ordering Information:


Connector

Fiber Type

Fiber Core

Polishing

Adaptor
 type

Flange

Housing
 Color

FC

Singlemode
 Multimode

Simplex
 Duplex

PC
 UPC
 APC

Big D
 Small D

Standard type
 FC type

Green
 White
 Black


image006(001).jpg     image008(001).jpg    image010(001).jpg



● Our Factory For Manufacturing:



Welcome to buy the fc upc big d type 13mm flange simplex singlemode/multimode metal adapter with our factory. As one of the leading manufacturers and suppliers in China, we also welcome the customized orders. Consult the price and the quotation with us now.
